3-1827253-6 by te connectivity / amp brand
Image is representational - see mfr. specs

3-1827253-6

TE Connectivity / AMP Brand

A 220-position, 0.5mm pitch SMT plug connector for parallel board-to-board stacking applications. ...

Datasheet
RoHS Compliant
Tray Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 3-1827253-6 is a 0.5mm Free Height (FH) SMT plug connector designed for parallel board-to-board stacking. It features 220 positions on a 0.5mm pitch, includes Giga ground shielding for signal integrity, and is part of the 5mm stacking height connector family. The connector is rated for 0.5A current, 50 VAC, and operates over a temperature range of -40°C to +85°C. Constructed with a UL94V-0 heat-resistant resin housing and gold-plated copper alloy contacts, it ensures durability for up to 30 mating cycles. This RoHS compliant connector is ideal for high-density applications in computing, telecommunications, and industrial equipment, including COM Express module-to-carrier card interfaces.

Product Highlights:

  • Plug
  • Family Name = Free Height
  • .50 mm Centerline
  • Number of Positions = 220
  • In-Line Contact Layout

Search Keywords: 318272536

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
3-1827253-6
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
30
Package Type:
Tray
Type:
Fine Pitch Connector
Body Orientation:
Straight
Gender:
PL
Mounting:
Surface Mount
Pitch:
0.5 mm
Number of Contacts:
220
Maximum Voltage Rating:
50 VAC
Maximum Current Rating:
0.5/Contact A
Termination Method:
Solder
Operating Temperature:
-40 to 85 °C

IN STOCK: 477

Ships today, if you order in

MOQ for out of Stock Qty: 330

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
1
$20.23
100
$15.35
250
$14.55
330
$13.83
660
$13.52
990
$13.45
1,320 +
$13.39
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides

Product Changes

Accessories

3-6318490-6

Stacking Board Connector - Free Height - FSI Series - 220 Contacts - Receptacle - 0.5 mm - ...
