350707-7 by te connectivity / amp brand
Image is representational - see mfr. specs

350707-7

TE Connectivity / AMP Brand

UMNL SPLIT PIN 20-14 AUBR L/P ...

Datasheet
RoHS Compliant
Bag Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

350707-7 is a loose piece wire-to-board connector contact designed for 5.0 mm Power Key Connectors (5.0 PKC) used in power circuits of home appliances, particularly gas appliances. The contact is manufactured from brass with select gold finish plating, featuring a minimum of 0.000030 inches (0.000762 mm) gold in the mating area over a 0.000050 inches (0.00127 mm) minimum nickel underplate on the entire contact. It accommodates wire sizes of 20-14 AWG (0.5-2.0 mm²) or dual 18 AWG (0.8 mm) configurations, with an insulation diameter range of 0.130-0.200 inches (3.30-5.08 mm) and a contact length (L dimension) of 0.810 inches (20.57 mm). This contact is commonly used in applications requiring reliable power connections with enhanced corrosion resistance and low contact resistance, making it suitable for demanding environments in appliance manufacturing.

Product Highlights:

  • Contact
  • Universal MATE-N-LOK
  • Not CompactPCI
  • Contact Type = Split Pin
  • Wire Range = 0.50-2.00² [20-14] mm [AWG]

Search Keywords: 3507077

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
350707-7
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Package Type:
Bag
Contact Type:
Power
Gender:
SKT
Contact Size:
N/A
Wire Size:
14-20 AWG
Contact Material:
Brass
Contact Plating:
Gold over Nickel
Maximum Current Rating:
13 A
Termination Method:
Crimp

IN STOCK: 6,086

Ships today, if you order in

MOQ for In Stock Qty: 50

MOQ for out of Stock Qty: 2500

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
50
$1.568
500
$1.565
1,000
$1.560
2,500
$1.556
5,000
$0.824
7,500
$0.580
10,000 +
$0.569
