3-640428-5 by te connectivity / amp brand

3-640428-5

TE Connectivity / AMP Brand

05P MTA156 CONN ASSY 22AWG RED ...

Datasheet
RoHS Compliant
Bag Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TE Connectivity / AMP Brand part 3-640428-5 is a 05P MTA156 connector assembly with 22 AWG red wires. This connector provides a reliable and secure connection for your electrical applications. It features a compact design and easy installation, making it suitable for various industrial and automotive projects. The 22 AWG red wires are color-coded for easy identification and ensure efficient power transmission. With its high-quality construction and dependable performance, this connector assembly is an ideal choice for your wiring needs.

Product Highlights:

  • Connector
  • 5 Positions
  • Connector Type = Receptacle
  • Connector Style = Closed End
  • MTA-156 Product Line

Search Keywords: 36404285

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
3-640428-5
RoHS:
Yes
HTS:
8536694040
COO:
US
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
250
Package Type:
Bag
Type:
IDC Connector
Body Orientation:
Right Angle
Gender:
F
Mounting:
Cable Mount
Pitch:
3.96 mm
Number of Contacts:
5
Maximum Voltage Rating:
600 VAC
Maximum Current Rating:
7/Contact A
Termination Method:
IDT
Operating Temperature:
-55 to 105 °C

IN STOCK: 19,750

Can Ship immediately

Minimum Order: 250

Multiple: 250

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
250
$0.2813
1,000
$0.2676
2,500
$0.2622
5,000
$0.2609
7,500
$0.2597
10,000
$0.2583
15,000
$0.2570
25,000 +
$0.2557
