640389-5 by te connectivity / amp brand

640389-5

TE Connectivity / AMP Brand

Wire-To-Board Connector - Right Angle - 3.96 mm - 5 Contacts - Header - MTA-156 Series - Through Hole. ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

Make strong and binding connections on your circuit boards by adopting this wire to board 640389-5 connector from TE Connectivity. This HDR connector's 5 contacts that are made out of copper alloy and plated with tin over nickel. It has a header type gender. Its pitch is 3.96 mm. It has a right angle body orientation. This is a 1-row connector. It has a maximum voltage rating of 600 VAC. This device has a maximum current rating of 7 A/contact. This connector has an operating temperature of -55 to 105 °C. This product is 19.81 mm long, 7.62 mm tall and 18.72 mm deep. 640389-5 is housed in white polyester. It uses the solder termination method.

Product Highlights:

  • MTA-156 Connectors
  • Number of Positions = 5
  • Mating Type = Header
  • Wire-to-Board Application
  • 3.96 mm Contact Centerline Spacing

Search Keywords: 6403895

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
640389-5
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Package Type:
Pack
Type:
Wire to Board
Body Orientation:
Right Angle
Gender:
HDR
Mounting:
Through Hole
Pitch:
3.96 mm
Number of Contacts:
5
Maximum Voltage Rating:
600 VAC
Maximum Current Rating:
7/Contact A
Termination Method:
Solder
Operating Temperature:
-55 to 105 °C

IN STOCK: 4,317

Can Ship immediately

Minimum Order: 50

Factory Lead-Time 13 Weeks

Price (USD)

Qty
Unit Price
50
$0.4508
500
$0.3164
1,000
$0.3080
3,000
$0.2914
5,000
$0.2899
8,000
$0.2885
10,000
$0.2871
15,000 +
$0.2856
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
