4-1571551-3 by te connectivity / amp brand
Image is representational - see mfr. specs

4-1571551-3

TE Connectivity / AMP Brand

CLOSED FRAME DIP, ECONOMY LEAD FREE (REF AUGAT 500 SERIES) ECONOMY (STAMPED CONTACT) ...

Datasheet
RoHS Compliant
Tube Packaging
Accessories
Discontinued
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

4-1571551-3 is a RoHS compliant closed frame DIP socket with four-fingered machined contacts designed for reliable IC-to-PCB connections. This socket features beryllium copper contacts with gold flash plating and a thermoplastic polyester insulator rated UL94 V-0. Technical specifications include a contact resistance of 10 milliohms maximum, contact rating of 3 Amps per pin, and dielectric withstanding voltage of 1,000 Volts RMS per EIA-364-20. The socket accepts IC pins ranging from 0.009" x 0.015" through 0.011" x 0.020", or 0.016" to 0.021" diameter. Common applications include industrial controls, intelligent buildings, medical devices, and other embedded systems where quick IC mating/unmating and easy field replacement are required.

Product Highlights:

  • DIP Socket
  • Number of Positions = 14
  • Row-to-Row Spacing = 7.62 mm
  • Thru Hole
  • Mount Style = Vertical

Search Keywords: 415715513

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
4-1571551-3
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CH
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
34
Package Type:
Tube
Type:
DIP Socket
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
SKT
Pitch:
2.54 mm
Number of Contacts:
14
Maximum Voltage Rating:
N/A
Maximum Current Rating:
3/Contact A
Operating Temperature:
-55 to 125 °C
Life Cycle:
Discontinued
  This product is discontinued, but still in stock
  Possible Replacement options available.  See Alternatives

IN STOCK: 4,726

Can Ship immediately

Minimum Order Quantity: 68

Multiple: 34

Price (USD)

Qty
Unit Price
68
$1.5450
272
$1.5141
476
$1.4935
918
$1.4626
1,360
$1.4214
10,030 +
$1.0401
