5103309-6 by te connectivity / amp brand

5103309-6

TE Connectivity / AMP Brand

Connector Header Through Hole 26 position 0.100" (2.54mm) ...

Datasheet
RoHS Compliant
Tube Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

TE Connectivity AMP-LATCH connectors are wire-to-board devices used to make the transition between cable and PC board circuitry. The mass termination capabilities of the AMP-LATCH family of connectors have made ribbon cable popular within the Electronics Industry. The ability to terminate up to 64 conductors simultaneously, without stripping or otherwise preparing the cable, saves labor. Contact Type Male Pin Pitch - Mating 0.100" (2.54mm) Number of Positions 26 Number of Rows 2 Row Spacing - Mating 0.100" (2.54mm) Number of Positions Loaded All Style Board to Cable/Wire Shrouding Shrouded - 4 Wall Mounting Type Through Hole Termination Solder Fastening Type Push-Pull Contact Finish - Mating Gold or Gold-Palladium Contact Finish Thickness - Mating 30.0µin (0.76µm) Contact Finish - Post Tin Contact Material Brass Features Keying Slot Operating Temperature -65°C ~ 105°C

Product Highlights:

  • Connector Type = Pin Headers
  • Low Profile
  • Number of Positions = 26
  • 2.54 x 2.54 mm Centerline, Matrix
  • PCB Mount Angle = Vertical

Search Keywords: 51033096

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5103309-6
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
60
Package Type:
Tube
Type:
Shrouded Header
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
2.54 mm
Number of Contacts:
26
Maximum Voltage Rating:
N/A
Maximum Current Rating:
1/Contact A
Termination Method:
Solder
Operating Temperature:
-65 to 105 °C

IN STOCK: 941

Can Ship immediately

Manufacturer Stock: 4,620   can ship 12/5/25

Minimum Order: 60

Multiple: 60

Factory Lead-Time 10 Weeks can ship 1/29/26

Price (CAD)

Qty
Unit Price
60
$3.293
120
$3.170
300
$3.063
540
$3.017
1,020
$3.002
2,520
$2.941
5,040 +
$2.924
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
Older Equivalent
281275-1
