5-146252-3 by te connectivity / amp brand
Image is representational - see mfr. specs

5-146252-3

TE Connectivity / AMP Brand

06 MODII HDR DRST B/A .100 LF ...

Datasheet
RoHS Compliant
Carton Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

5-146252-3 is a single-row breakaway header with solder tails, part of the AMPMODU .100 [2.54] centerline interconnection system. This header features a .025 [0.64] square straight post design and is available in various position configurations. The component is designed for surface mount applications with specific dimensional parameters including C = .125 [3.18], D = .318 [8.08], and E = .200 [5.08]. These headers are commonly used in board-to-board interconnection applications where reliable electrical connections and flexible position configurations are required.

Product Highlights:

  • Header
  • Header Type = Breakaway
  • Number of Rows = Dual
  • Number of Positions = 6
  • Mating Post Length = 8.08 mm

Search Keywords: 51462523

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5-146252-3
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
520
Package Type:
Carton
Type:
Unshrouded Header
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
2.54 mm
Number of Contacts:
6
Maximum Voltage Rating:
N/A
Maximum Current Rating:
3/Contact A
Termination Method:
Solder
Operating Temperature:
-65 to 105 °C

IN STOCK: 19,937

Ships today, if you order in

Minimum Order Quantity: 50

Factory Lead-Time 18 Weeks

Price (USD)

Qty
Unit Price
50
$0.5376
250
$0.3891
520
$0.3872
1,040
$0.3846
2,600
$0.3809
5,200
$0.3790
7,800
$0.3771
10,400 +
$0.3752
Suppliers Standard Package
