5-146253-5 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

5-146253-5

10 MODII HDR DRST B/A .100CL L ...

View Datasheet Ask the Datasheet
RoHS Compliant
BOX Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The TE Connectivity / AMP BRAND 5-146253-5 is a high-quality ten-position header with a dual row, straight angle design, perfect for circuit board connections. Featuring a 0.100" centerline spacing, this header is designed for optimal performance and ease of use in your electrical projects.

Product Highlights:

  • Header
  • Header Type = Breakaway
  • Number of Rows = Dual
  • Number of Positions = 10
  • Mating Post Length = 8.08 mm

Search Keywords: 51462535

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5-146253-5
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
320
Package Type:
BOX
Type:
Unshrouded Header
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
2.54 mm
Number of Contacts:
10
Maximum Voltage Rating:
N/A
Maximum Current Rating:
3/Contact A
Termination Method:
Solder
Operating Temperature:
-65 to 105 °C

IN STOCK: 5,346

Can Ship immediately

MOQ for In Stock Qty: 25

MOQ for out of Stock Qty: 1600

Factory Lead-Time 18 Weeks

Price (USD)

Qty
Unit Price
25
$1.466
500
$1.025
1,000
$1.023
1,600
$1.020
3,200
$1.018
4,800
$1.015
6,400 +
$0.974
Log in for special pricing Click for Quote Price Match Request
