5745072-2 by te connectivity / amp brand
Image is representational - see mfr. specs

5745072-2

TE Connectivity / AMP Brand

HD-20 PLUG 15P VERT FFSCRLK ...

Datasheet
RoHS Compliant
Tube Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

5745072-2 is an HD-20 subminiature D-type receptacle connector designed for secure PCB mounting with fixed female screwlocks. This connector features 15 contact positions and is available with contact finish plating code A (phosphor bronze with .000030 [0.00076] gold on mating end, tin on termination end, and .000050 [0.00127] minimum nickel underplate) or code B (gold flash on mating end with tin termination). The connector has a shell size of 2 with overall dimensions of 1.546 inches (39.27 mm) length and 1.312 inches (33.33 mm) width, with a profile depth of .420 inches (10.67 mm). Post lengths are available at .125 inches (3.18 mm) for PCB thickness of .062–.093 inches (1.58–2.36 mm) or .170 inches (4.32 mm) for PCB thickness of .093–.125 inches (2.36–3.18 mm). This connector is commonly used in applications requiring reliable signal transmission and mechanical retention in compact electronic assemblies.

Product Highlights:

  • 15 Positions
  • With Contacts
  • Housing Gender = Plug
  • PCB Mount Angle = Vertical
  • Product Series = HD 20

Search Keywords: 57450722

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5745072-2
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
13
Package Type:
Tube
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
Pin
Termination Method:
Solder
Shell Size:
2
Number of Contacts:
15
Contact Plating:
Gold Over Nickel,Gold Over Palladium Nickel Over Nickel
Operating Temperature:
N/A

IN STOCK: 1,216

Can Ship immediately

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 205

Factory Lead-Time 10 Weeks

Price (USD)

Qty
Unit Price
5
$18.36
50
$18.31
100
$18.27
205
$18.22
410
$9.65
615
$6.79
819 +
$6.65
