5745434-8 by te connectivity / amp brand

5745434-8

TE Connectivity / AMP Brand

09 PLUG RA/MS 454 ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TE Connectivity / AMP Brand part 5745434-8 is a 09 Plug RA/MS 454. This compact and versatile connector is designed to provide a secure and reliable connection in a wide range of applications. The right angle design allows for easy installation and space-saving in tight spaces. With its robust construction and high-quality materials, this connector ensures long-lasting performance and durability. Whether used in automotive, aerospace, or industrial applications, the TE Connectivity / AMP Brand part 5745434-8 is a trusted choice for reliable connectivity.

Product Highlights:

  • Number of Positions = 9
  • Plug
  • PCB Mount Angle = Right Angle
  • Product Series = HD 20
  • With Mating Connector Lock

Search Keywords: 57454348

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5745434-8
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
140
Package Type:
Pack
Type:
D-Subminiature
Body Orientation:
Right Angle
Mounting:
Through Hole
Gender:
Pin
Termination Method:
Solder
Shell Size:
1
Number of Contacts:
9
Contact Plating:
Gold Over Nickel,Gold Over Palladium Nickel Over Nickel
Operating Temperature:
N/A

IN STOCK: 397

Can Ship immediately

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 140

Factory Lead-Time 23 Weeks

Price (USD)

Qty
Unit Price
5
$15.429
25
$13.225
50
$12.690
100
$12.442
140
$11.794
280
$11.237
420
$11.176
560 +
$10.877
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
