5745967-7 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

5745967-7

D Sub Connector - DB25 - 25 Contacts - Receptacle - Through Hole - DB - AMPLIMITE HD-20 Series. ...

View Datasheet Ask the Datasheet
RoHS Compliant
TUBE Packaging
Accessories
Certificate of Compliance

DESCRIPTION

Be sure to set up proper communication between your serial connections with the 5745967-7 DVI connector from TE Connectivity. This socket type connector's 25 contacts that are made out of phosphor bronze and plated with gold over nickel. This 2-row connector has a single port. It has a maximum voltage rating of 250 VAC. It has a straight body orientation. Its pitch is 2.77 mm. 5745967-7 is housed in polyester. In order to ensure parts aren't damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This DVI connector has an operating temperature of -55 to 105 °C. Its 25 terminals use the solder termination method. This product is 53.09 mm long, 12.16 mm tall and 12.55 mm deep.

Product Highlights:

  • 25 Positions
  • Receptacle
  • PCB Mount Angle = Vertical
  • Product Series = HD 20
  • With Mating Connector Lock

Search Keywords: 57459677

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5745967-7
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
10
Package Type:
TUBE
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
SKT
Termination Method:
Solder
Shell Size:
3
Number of Contacts:
25
Contact Plating:
Gold over Nickel
Operating Temperature:
-55 to 105 °C

IN STOCK: 1,034

Ships today, if you order in

Minimum Order Quantity: 10

Multiple: 10

Factory Lead-Time 30 Weeks

Price (USD)

Qty
Unit Price
10
$6.86
30
$6.84
100
$6.67
250
$6.56
500
$6.53
1,000
$5.85
2,500 +
$4.88
Supplier's Standard Package
Log in for special pricing

Tools/3D Models

Product Guides

Accessories

1-745496-8

25 HDE MS PLUG,22-26,LEAD FREE

1-747547-0

KIT,PLUG,25P,HDE,SHLD HDWRE

1-747948-8

KIT,PLUG,25P,HDE,SHLD ENCLSRE

1571652-4

LF PLUG KIT,SIZE 3,7.2MM

1571652-5

LF PLUG KIT,SIZE 3,9.5MM

1571652-6

A 25-position, shell size 3, HD-20 D-subminiature plug connector kit with solder cup conta ...

Show 4 More
