5747871-8 by te connectivity / amp brand

5747871-8

TE Connectivity / AMP Brand

9 Position D-Sub Plug, Male Pins Connector ...

Datasheet
RoHS Compliant
Tube Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 5747871-8 is a 9-position 2-row standard D-sub Plug with gold-plated brass contacts, 4-40 threaded inserts and size-1 tin-plated steel shell. The HD-20 straight posted connector in front metal-shell. The HD-20 connector has action pin contacts. UL94V-0 Rated black thermoplastic housing Number of Positions: 9 Position Contact Gender: Pin (Male) Termination Style: Through Hole Number of Rows: 2 Row Shell Size: 1 (E) Contact Plating: Gold Packaging: Tube Gender: Male Type: Plug Shell Material: Steel Applications Industrial

Product Highlights:

  • Number of Positions = 9
  • Plug
  • PCB Mount Angle = Vertical
  • Product Series = HD 20
  • With Mating Connector Lock

Search Keywords: 57478718

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5747871-8
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
17
Package Type:
Tube
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
Pin
Termination Method:
Solder
Shell Size:
1
Number of Contacts:
9
Contact Plating:
Gold over Nickel
Operating Temperature:
-55 to 105 °C

IN STOCK: 1,775

Can Ship immediately

Minimum Order: 17

Multiple: 17

Factory Lead-Time 15 Weeks

Price (USD)

Qty
Unit Price
17
$3.430
51
$3.389
102
$3.327
255
$3.245
510
$3.193
1,003
$3.183
2,516
$3.162
5,015 +
$3.152
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides

Product Changes

Accessories

1-747943-5

KIT,RCPT,9P,HDE,SHLD ENCLSRE

1-745491-9

RCPT ASSY,9P,HDE,MS

1-747943-6

KIT,RCPT,9P,HDE,SHLD ENCLSRE

1658610-4

9 Position D-Sub Receptacle, Female Sockets Connector

1-745491-7

09 HDE MS RCPT,22-26,LEAD FREE

1-745491-6

09 HDE MS RCPT,26-30,LEAD FREE

1658612-4

09 POS HDF RCPT, MS, LEAD FREE

5746861-4

9 POS HDF RCPT, MS

747516-7

09 HDE PMOLD RCPT, LEAD FREE
