5747832-6

DESCRIPTION

5747832-6 is a right-angle posted subminiature D (D-sub) plug connector from the TE Connectivity AMPLIMITE series, designed for reliable PCB-to-cable interconnections. This shell size 1 connector features 9 contact positions with size 20 DF posted pin contacts preloaded, and includes fixed female screwlocks for secure mating along with boardlocks for stable PCB mounting. Key dimensions include A: 1.213 inches (30.81 mm), B: 0.984 inches (24.99 mm), D: 0.235 inches (5.97 mm), and E: 0.965 inches (24.51 mm). The contact finish uses plating code A, featuring 0.000030 inch (0.00076 mm) gold on the mating end and tin on the termination end with nickel underplating throughout. This RoHS-compliant connector is ideal for applications requiring robust signal connections in industrial, computing, and communication equipment.

Product Highlights:

9 Positions
Plug
PCB Mount Angle = Right Angle
Product Series = HD 20
With Mating Connector Lock

Potential Applications:

Search Keywords: 57478326
