6-104068-3 by te connectivity / amp brand
Image is representational - see mfr. specs

6-104068-3

TE Connectivity / AMP Brand

34 SYSTEM 50 HDR DRST SHRD ...

Datasheet
RoHS Compliant
Tube Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

6-104068-3 is a double row right-angle shrouded header from the AMPMODU System 50 interconnection system, designed for board-to-board applications. This 34-position connector features a 0.050 inch [1.27 mm] pitch with a post length of 0.100 inch [2.54 mm] and Dimension A of 0.980 inch [24.89 mm]. The housing is constructed from glass-filled thermoplastic in black with UL 94V-0 flammability rating, while contacts are copper alloy with duplex plating featuring 0.000030 inch [0.00076 mm] gold in the mating area, 0.000150 inch [0.00381 mm] tin on solder posts, and 0.000050 inch [0.00127 mm] nickel underplating. This RoHS compliant connector is suitable for reliable PCB interconnection in various electronic applications.

Product Highlights:

  • Header Assembly
  • Number of Positions = 34
  • Number of Rows = Dual
  • Shrouded
  • Vertical Mount Angle

Search Keywords: 61040683

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
6-104068-3
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
19
Package Type:
Tube
Type:
Shrouded Header
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
1.27 mm
Number of Contacts:
34
Maximum Voltage Rating:
30 VAC
Maximum Current Rating:
N/A
Termination Method:
Solder
Operating Temperature:
-65 to 105 °C

IN STOCK: 1,254

Can Ship immediately

On Order: 342   can ship 6/17/26

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 200

Factory Lead-Time 17 Weeks

Price (USD)

Qty
Unit Price
5
$7.16
50
$5.59
100
$5.27
200
$5.18
399
$5.15
599
$5.13
798 +
$5.10
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides

Accessories

6-104078-0

34 SYSTEM 50 RCPT ASSY DRST SN

3-487937-4

034 HOUSING FFC 50CL DR LATCH

3-111196-0

034 RCPT SYSTEM 50 30 DPLX

Show 1 More
