6-146256-0 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

6-146256-0

20 MODII HDR DRST B/A .100CL L ...

View Datasheet Ask the Datasheet
RoHS Compliant
BOX Packaging
Accessories
Certificate of Compliance

DESCRIPTION

6-146256-0 is an AMPMODU double-row unshrouded breakaway header with solder tails and board retention tails, designed for board-to-board interconnection applications. This 80-position header features a .100 [2.54] centerline pitch with dimensions A = 3.984 [101.19] inches and B = 3.900 [99.06] inches. The header includes C dimension of .120 [3.05] inches, D dimension of .230 [5.84] inches, and E dimension of .185 [4.70] inches. The breakaway design allows customization to desired position counts, while the retention tails provide secure board mounting. This component is commonly used in electronic interconnection systems requiring reliable multi-position connections.

Product Highlights:

  • Header
  • Header Type = Breakaway
  • Number of Rows = Dual
  • Number of Positions = 20
  • Mating Post Length = 5.84 mm

Search Keywords: 61462560

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
6-146256-0
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
200
Package Type:
BOX
Type:
Unshrouded Header
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
2.54 mm
Number of Contacts:
20
Maximum Voltage Rating:
N/A
Maximum Current Rating:
3/Contact A
Termination Method:
Solder
Operating Temperature:
-65 to 105 °C

IN STOCK: 2,801

Can Ship immediately

MOQ for In Stock Qty: 10

MOQ for out of Stock Qty: 1000

Factory Lead-Time 21 Weeks

Price (USD)

Qty
Unit Price
10
$3.68
250
$2.40
500
$2.32
1,000
$2.24
2,000
$2.22
3,000
$2.21
4,000 +
$2.20
