640500-3 by te connectivity / amp brand
Image is representational - see mfr. specs

640500-3

TE Connectivity / AMP Brand

06P MR HDR ASSY V0 ...

Datasheet
RoHS Compliant
Bag Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

640500-3 is a 6-circuit vertical PC board pin header designed for wire-to-board interconnect applications. This header features tin plating and is configured for 0.120 inch (3.05 mm) board thickness with matrix-style circuit arrangement. The connector has dimension A of 0.620 inch (15.75 mm) and dimension B of 0.180 inch (4.57 mm), and mates with socket housing part number 1-640520-0. Part of the AMP Soft Shell Miniature Rectangular (MR) connector series, this header is RoHS compliant and suitable for applications requiring reliable pin and socket connections in electronic assemblies.

Product Highlights:

  • Header
  • Number of Circuits = 6
  • 4.19 x 4.19 mm Centerline, Matrix
  • Matrix Contact Layout
  • Mount = PCB Thru Mount

Search Keywords: 6405003

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
640500-3
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
200
Package Type:
Bag
Type:
Rectangular
Mounting:
Through Hole
Body Orientation:
Straight
Gender:
RCP
Pitch:
4.19 mm
Termination Method:
Solder
Number of Contacts:
6
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
9/Contact A
Operating Temperature:
-55 to 105 °C

IN STOCK: 2,000

Can Ship immediately

MOQ for In Stock Qty: 10

MOQ for out of Stock Qty: 600

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
10
$5.481
100
$3.617
250
$3.504
600
$3.360
1,200
$3.252
1,800
$3.241
2,400 +
$3.234
