796136-1 by te connectivity / amp brand
Image is representational - see manufacturer specifications

796136-1

TE Connectivity / AMP Brand

ASSY, SMT BATTERY CONN ...

Datasheet
RoHS Compliant
REEL Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

ASSY, SMT BATTERY CONN

Product Highlights:

  • Battery Holder
  • Number of Positions = 2
  • Horizontal Mount Angle
  • No PCB Retention Feature
  • Without Mounting Holes

Search Keywords: 7961361

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
796136-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
400
Package Type:
REEL
Type:
Battery
Body Orientation:
Right Angle
Mounting:
Surface Mount
Gender:
N/A
Number of Contacts:
2
Termination Method:
Solder
Maximum Voltage Rating:
30 VAC
Maximum Current Rating:
N/A
Operating Temperature:
N/A

IN STOCK: 2,495

Can Ship immediately

Manufacturer Stock: 2,400   can ship 8/3/26

On Order: 2,400   can ship 11/23/26

Minimum Order Quantity: 400

Factory Lead-Time 18 Weeks can ship 11/23/26

Price (USD)

Qty
Unit Price
400
$1.15
800
$1.14
1,200
$1.13
2,800
$1.12
5,200
$1.11
7,600 +
$1.10
Reel Package
