M39029/1-102 by te connectivity / deutsch
Image is representational - see mfr. specs

M39029/1-102

TE Connectivity / Deutsch

Contact PIN Crimp ST Cable Mount ...

Datasheet
RoHS Non-Compliant
Box Packaging
Accessories
Discontinued
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

M39029/1-102 is a military-specification pin contact designed for size 16 terminal junction systems compliant with MIL-T-81714. The contact is rated for a dielectric withstanding voltage (DWV) of 1,500V at sea level and 600V at 70,000 feet altitude, with a working voltage of 600V at sea level and 300V at altitude. It exhibits a maximum contact voltage drop of 50V initially and 55V after conditioning at a test current of 13.0A, and maintains an insulation resistance of at least 5,000 megohms after three altitude immersion cycles in salt water. The contact operates reliably across a temperature range of -65°C to +200°C and demonstrates excellent durability with no performance degradation after 10 insertion/removal cycles. These specifications make it suitable for demanding aerospace and military applications requiring high reliability and environmental resistance.

Search Keywords: M390291102

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Deutsch
Part No:
M39029/1-102
Alias/AKA:
ZPF000000000205408
Unit of Measure:
Per Each
RoHS:
No
HTS:
8536904000
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Box
Contact Type:
N/A
Gender:
Pin
Contact Size:
16
Wire Size:
N/A
Contact Material:
Brass
Contact Plating:
Gold over Nickel
Maximum Current Rating:
N/A
Termination Method:
Crimp
Life Cycle:
Discontinued
  This product is discontinued, but still in stock
  This product is NOT RoHS Compliant.  See Alternatives

IN STOCK: 2,161

Ships today, if you order in

Minimum Order Quantity: 24

Price (USD)

Qty
Unit Price
24
$2.76
10,000
$1.57
25,000
$1.38
50,000
$1.18
100,000
$1.13
250,000
$1.08
500,000 +
$1.02
