PCN-105D3MHZ,000 by te connectivity / p-b brand

PCN-105D3MHZ,000

TE Connectivity / P&B Brand

Power Relay 5VDC 3A SPST-NO(20mm 5mm 12.5mm) THT ...

Datasheet
RoHS Compliant
Tube Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TE Connectivity / P&B Brand part PCN-105D3MHZ,000 is a compact and reliable power relay designed for electronic applications. With a low operating voltage of 5VDC and a maximum current of 3A, this relay provides a dependable switch for controlling various electrical circuits. The SPST-NO (Single Pole Single Throw Normally Open) configuration offers a simple and versatile connection, while the through-hole technology (THT) mounting style ensures secure and convenient installation. Measuring just 20mm x 5mm x 12.5mm, this power relay is compact and space-saving, making it an excellent choice for compact electronic designs. Trust in the TE Connectivity / P&B Brand PCN-105D3MHZ,000 to deliver efficient and reliable performance in your power control applications.

Product Highlights:

  • PCN Series
  • Contact Arrangement = 1 Form A, SPST-NO, 1 N/O
  • Contact Current Rating = 3 Amps.
  • Monostable Coil Magnetic System
  • Without Coil Suppression Diode

Search Keywords: PCN105D3MHZ000

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
PCN-105D3MHZ,000
RoHS:
Yes
HTS:
8536698000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
Tube
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
5 V
Contact Arrangement:
SPST-NO
Maximum Current Rating:
3 A
Mounting:
Through Hole
Termination Style:
PC Pin
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-30 to 70 °C
Coil Resistance:
208 Ohm

IN STOCK: 0

On Order: 2,862   can ship 2/25/26

MOQ for In Stock Qty: 25

MOQ for out of Stock Qty: 500

Multiple: 25

Factory Lead-Time 16 Weeks
