SKHHLSA010 by alps electric
Image is representational - see mfr. specs

SKHHLSA010

Alps Electric

Switch Tactile N.O. SPST Round Button PC Pins 0.05A 12VDC 2.55N Thru-Hole Bulk ...

Datasheet
RoHS Compliant
BULK Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

SKHHLSA010 is a 6mm square snap-in type tactile push switch designed for side-push applications with a 2.55N operating force. This switch features a red stem color and is rated for 200,000 operating cycles at 5mA 5V DC, providing reliable performance in consumer electronics and industrial control applications. The device operates with a maximum rating of 50mA at 12V DC and a minimum rating of 10µA at 1V DC, with an initial contact resistance of 100mO maximum and a travel distance of 0.25mm. The switch is suitable for applications requiring compact, user-friendly push-button interfaces with moderate actuation force and long operational life.

Search Keywords: SKHHLSA010

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Alps Electric
Part No:
SKHHLSA010
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509031
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10000
Package Type:
BULK
Dimension:
7.5 x 12.35 x 7.4 mm
Mounting:
PCB Through Hole
Pole Throw Configuration:
SPST
Switch Configuration:
N.O.
Actuator Style:
Round Button
Operating Force:
2.55 N
Contact Rating @ Voltage:
0.05@12VDC A
Illumination Type:
N/R
Body Orientation:
Right Angle
Termination Style:
PC Pins
Seal Location:
N/A

IN STOCK: 8,100

Ships today, if you order in

Minimum Order Quantity: 250

Factory Lead-Time 18 Weeks

Price (USD)

Qty
Unit Price
250
$0.1738
2,500
$0.1146
5,000
$0.1135
7,500
$0.1099
30,000
$0.1065
50,000
$0.1060
100,000
$0.1055
150,000 +
$0.1050
Log in for special pricing Click for Quote Price Match Request
