Image is representational - see manufacturer specifications
Honeywell Authorized Distributor

3LS1

MICRO SWITCH™ General Purpose Limit Switches: LS Series, Epoxy-Coated Zinc Housing, Non Plug-in Body Style, Side Roller Plunger, Ø 16,7 mm x 4,8 mm [0.66 in x 0.19 in] SST Roller, Roller Plunger May Be Locked in Any Position Through 360°, 1NC 1NO Single Pole Double Throw (SPDT) Snap Action, Double Break, 10 A 120, 240, or 480 Vac, 0.5 in - 14 NPT Conduit, Operating Temperature: -29 °C to 71 °C [-20 °F to 160 °F], NEMA 1, 3, 4, 6 and 13 ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The HONEYWELL part 3LS1 is a MICRO SWITCH„¢ General Purpose Limit Switch that features an epoxy-coated zinc housing and a non-plug-in body style. It has a side roller plunger with a diameter of 16.7 mm and a thickness of 4.8 mm. The switch is equipped with a stainless steel roller with a diameter of 0.66 in and a thickness of 0.19 in.The unique design of this limit switch allows the roller plunger to be locked in any position through 360°, providing versatility in various applications. It has a 1NC 1NO single pole double throw (SPDT) snap action, double break configuration.With a current rating of 10 A and voltage options of 120, 240, or 480 Vac, this switch is capable of handling a wide range of electrical loads. It features a 0.5 in - 14 NPT conduit for easy installation and is designed to operate in temperatures ranging from -29 °C to 71 °C (-20 °F to 160 °F).The 3LS1 limit switch has a NEMA 1, 3, 4, 6, and 13 rating, making it suitable for use in various indoor and outdoor environments. It is a reliable and durable solution for applications that require accurate and dependable position sensing.

Product Highlights:

  • Mode of operation is field adjustable
  • NEMA 1, 3, 4, 6, and 13
  • Wide choice of heads and actuators
  • Variety of operating characteristics
  • Captive screws
  • UL and CSA approved parts available

Potential Applications:

  • Machine tools
  • Conveyors
  • Material handling
  • Metal fabrication equipment
  • Lift trucks

Search Keywords: 3LS1

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
3LS1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
85365009
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
10
Type:
Enclosed
Actuator Style:
Side Roller Plunger
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Operating Force:
40.03 N
Dimension:
39.88 x 70.33 x 93.98 mm
Maximum Current Rating:
0.8@115VDC A
Terminal Type:
Conduit
NEMA Standard as Enclosure Rating:
1, 3, 4, 6, 13
Body Orientation:
Right Angle

IN STOCK: 19

Can Ship immediately

On Order: 15   can ship 3/15/27

Factory Lead-Time 44 Weeks
