ELG-240-24 by mean well

ELG-240-24

Mean Well

AC/DC - LED - Power Sply - Const Curr/Volt - 240W - Fixed: 24 Vdc - 10,000mA - Dim: No ...

Datasheet
RoHS Compliant
Packaging
Accessories
End of Life: Final orders must be placed by 12/30/2025
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The ELG-240-24 is a LED Driver in 240W variant. This LED driver operates on rated voltage ov 24V. Thanks to a high efficiency (up to 93%), and a fanless design, this series is able to operate with -40°C ~ +90°C case temperatures under free air convection. The design of metal housing and IP67/IP65 ingress protection level allows these drivers to be viable in both indoor and outdoor applications.

Search Keywords: ELG24024

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Mean Well
Part No:
ELG-240-24
RoHS:
Yes
HTS:
8504409530
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Input/Output Type:
AC/DC8097
Style:
Enclosed
Type:
Constant Current/Voltage
Output Type:
Fixed
Dimming:
No
Maximum Output Power:
240 W
Output Voltage Range:
12.0 to 24.0 Vdc
Maximum Output Current:
10,000 mA (10.0 A)
Minimum AC Input Voltage:
100
Maximum AC Input Voltage:
305
Minimum DC Input Voltage:
142
Maximum DC Input Voltage:
431
Termination Style:
Wire Leads
Input Connector Type:
Stripped and Tinned
Output Connector Type:
Stripped and Tinned
Operating Temperature:
-40 to 90 °C
Safety Agency Approvals:
CB, CCC, CE, cRUus, RCM
IEC Class:
None
SELV:
No
LPS:
No
Warranty:
5 Years
Family:
ELG-240
End of Life:
Final orders must be placed by 12/30/2025
  End of Life: Final orders must be placed by 12/30/2025

IN STOCK: 65

Can Ship immediately

Factory Lead-Time 16 Weeks
