1755781 by phoenix contact
Image is representational - see manufacturer specifications
Phoenix Contact Authorized Distributor

1755781

PCB headers - nominal current: 12 A - rated voltage (III/2): 320 V - nominal cross section: 2.5 mm² - number of positions: 7 - pitch: 5.08 mm - color: green - contact surface: Tin - mounting: Wave soldering - pin layout: Linear pinning - solder pin [P]: 3.9 mm ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The PHOENIX CONTACT part 1755781 is a high-quality PCB header designed for efficient electrical connections. With a nominal current rating of 12A and a rated voltage of 320V, this header ensures reliable and safe operation. The 2.5mm² nominal cross section ensures sufficient power transmission, while the 7-position layout allows for versatile applications.The 5.08mm pitch facilitates easy installation and secure connections. This PCB header comes in a vibrant green color, making it easy to identify and differentiate. The tin contact surface improves conductivity and longevity, while the wave soldering mounting method enables quick and efficient assembly.Featuring a linear pin layout and 3.9mm solder pin length, this header offers compatibility with a wide range of PCB designs and applications. Whether used in industrial controls or electronic systems, the PHOENIX CONTACT part 1755781 provides a reliable and durable solution for your electrical connectivity needs.

Search Keywords: 1755781

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1755781
Alias/AKA:
1755781
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
100
Type:
Shrouded Header (4 Sides)
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
5.08 mm
Number of Contacts:
7
Maximum Voltage Rating:
250@IEC,300@UL V
Maximum Current Rating:
12 A
Termination Method:
Solder
Operating Temperature:
N/A

IN STOCK: 1,000

Can Ship immediately

On Order: 1,000   can ship 2/8/27

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
100
$1.86
300
$1.80
500
$1.79
1,000
$1.77
2,500
$1.75
5,000
$1.74
7,500
$1.71
10,000 +
$1.70
Supplier's Standard Package
Log in for special pricing

Tools/3D Models

Product Guides

Product Changes

Accessories

1734401

Coding section - inserted into the recess in the header or the inverted plug - red insulat ...

1755477

Connector Accessories Cap Straight Green
