1777112 by phoenix contact
Image is representational - see manufacturer specifications
Phoenix Contact Authorized Distributor

1777112

PCB headers - nominal current: 12 A - rated voltage (III/2): 320 V - nominal cross section: 2.5 mm² - number of positions: 6 - pitch: 5.08 mm - color: green - contact surface: Tin - mounting: Wave soldering - pin layout: Linear pinning - solder pin [P]: 3.9 mm ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The PCB header part 1777112 from PHOENIX CONTACT is a green-colored component designed for wave soldering mounting. It has a linear pin layout with 6 positions, a pitch of 5.08 mm, and a rated voltage of 320 V. With a nominal current of 12 A and a nominal cross-section of 2.5 mm², this header is reliable for various electrical connections. The contact surface is coated with tin for optimal conductivity, and the solder pin measures 3.9 mm.

Search Keywords: 1777112

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1777112
Alias/AKA:
1777112
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
100
Type:
Shrouded Header (4 Sides)
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
5.08 mm
Number of Contacts:
6
Maximum Voltage Rating:
320 V
Maximum Current Rating:
12 A
Termination Method:
Solder
Operating Temperature:
N/A

IN STOCK: 181

Ships today, if you order in

Minimum Order Quantity: 5

Factory Lead-Time 15 Weeks

Price (USD)

Qty
Unit Price
5
$5.05
50
$3.55
100
$3.51
300
$3.48
500
$3.47
1,000
$3.46
2,500
$3.45
5,000 +
$3.44
