1586844-1

TE Connectivity / AMP Brand

09P UMNL PLUG HSG NATL, GW ...

Datasheet

RoHS Compliant

Bag Packaging

Certificate of Compliance Guarantee

DESCRIPTION

The 1586844-1 is a 9-circuit universal Mate-N-Lok plug connector housing manufactured by TE Connectivity/AMP. The housing is constructed from nylon material with UL94V-2 flammability rating and meets multiple international safety standards including IEC 60695 glow-wire flammability and ignition tests across various thickness specifications (0.38 mm to 3.0 mm). Key dimensional specifications include a length of 27.43 ± 0.38 mm and a width of 20.32 mm, with tolerance of ± 0.13 mm for 2 decimal place dimensions. The connector mates with appropriate universal Mate-N-Lok caps or headers and features optional rib configurations for enhanced structural integrity. This connector housing is widely used in automotive, industrial, and telecommunications applications where reliable multi-circuit connections and compliance with international safety standards are required.

Product Highlights:

Potential Applications:

Search Keywords: 15868441

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

TE Connectivity / AMP Brand

Part No:

1586844-1

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8538906000

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
