4-640426-0 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

4-640426-0

Wire-To-Board Connector - 3.96 mm - 10 Contacts - Receptacle - MTA-156 Series - IDC / IDT - 1 Rows. ...

View Datasheet Ask the Datasheet
RoHS Compliant
BAG Packaging
Accessories
Certificate of Compliance

DESCRIPTION

Use this idc connector 4-640426-0 connector from TE Connectivity when board-to-board interconnects is required. This F connector's 10 contacts that are made out of copper alloy and plated with tin over nickel. It has a maximum voltage rating of 600 VAC. It has a female type gender. It has a right angle body orientation. Its pitch is 3.96 mm. This is a 1-row connector. This device has a maximum current rating of 7 A/contact. This product is 39.62 mm long, 9.02 mm tall and 18.42 mm deep. This connector has an operating temperature of -55 to 105 °C. It uses the idt termination method. 4-640426-0 is housed in orange nylon.

Product Highlights:

  • MTA-156 Connectors
  • Number of Positions = 10
  • Mating Type = Receptacle
  • Connector Type = Closed End
  • Wire-to-Board Application

Search Keywords: 46404260

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
4-640426-0
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
US
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
250
Package Type:
BAG
Type:
IDC Connector
Body Orientation:
Right Angle
Gender:
F
Mounting:
Cable Mount
Pitch:
3.96 mm
Number of Contacts:
10
Maximum Voltage Rating:
600 VAC
Maximum Current Rating:
7/Contact A
Termination Method:
IDT
Operating Temperature:
-55 to 105 °C

IN STOCK: 5,577

Ships today, if you order in

Minimum Order Quantity: 250

Multiple: 250

Factory Lead-Time 24 Weeks

Price (USD)

Qty
Unit Price
250
$0.768
500
$0.761
1,000
$0.720
2,500
$0.679
5,000
$0.654
7,500
$0.653
10,000
$0.651
15,000 +
$0.649
