5747842-2 by te connectivity / amp brand
Image is representational - see mfr. specs

5747842-2

TE Connectivity / AMP Brand

25 MSFL PLUG RA 318 (FM,BL) ...

Datasheet
RoHS Compliant
Tray Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

5747842-2 is a 25-position right-angle posted D-subminiature plug connector from the AMPLIMITE series, designed for reliable PCB board mounting applications. This shell size 3 connector features threaded inserts (4-40) for secure mating hardware and includes boardlocks for stable PCB attachment. The connector is preloaded with size 20 DF posted pin contacts with duplex plating (0.000030" gold on mating end, tin on termination end, nickel underplated). Key dimensions include A: 2.088" (53.04 mm), B: 1.852" (47.04 mm), D: 0.230" (5.84 mm), and E: 0.738" (18.75 mm). Recommended PCB board thickness is 0.062" (1.58 mm) for connectors with boardlocks, making it suitable for industrial, computing, and communication equipment requiring robust D-sub interconnections.

Product Highlights:

  • Number of Positions = 25
  • Plug
  • PCB Mount Angle = Right Angle
  • Product Series = HD 20
  • Without Mating Connector Lock

Search Keywords: 57478422

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5747842-2
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
65
Package Type:
Tray
Type:
D-Subminiature
Body Orientation:
Right Angle
Mounting:
Through Hole
Gender:
Pin
Termination Method:
Solder
Shell Size:
3
Number of Contacts:
25
Contact Plating:
Gold over Nickel
Operating Temperature:
N/A

IN STOCK: 2,878

Ships today, if you order in

Minimum Order Quantity: 5

Factory Lead-Time 10 Weeks

Price (USD)

Qty
Unit Price
5
$8.64
25
$6.81
65
$6.46
130
$6.39
260
$6.14
520
$5.84
1,040
$5.58
2,535 +
$5.55
Suppliers Standard Package
