609-1041LF by te connectivity / buchanan brand
Image is representational - see mfr. specs

609-1041LF

TE Connectivity / Buchanan Brand

A 10-position, 609 Series female socket connector with strain relief, featuring military and center polarization for terminating ribbon cable. ...

Datasheet
RoHS Compliant
Tray Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 609-1041LF is a 10-position female socket connector from the 609 Series, supplied with a pre-installed strain relief. It features both military and center polarization to ensure correct mating with compatible headers. The connector is designed for mass termination of 28-30 AWG ribbon cable, utilizing a dual-slot Insulation Displacement Contact (IDC) design. Its contacts are made of beryllium copper with gold plating on the mating end, and the housing is a blue, UL 94V-0 rated glass-filled thermoplastic. This connector is ideal for creating reliable wire-to-board interconnections on a .100" x .100" grid in various electronic systems.

Product Highlights:

  • Connector Type = AMP-LATCH
  • Number of Positions = 10
  • Receptacle
  • Mating Polarization Method = Center & Military
  • With Mating Polarization

Search Keywords: 6091041LF

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Buchanan Brand
Part No:
609-1041LF
Alias/AKA:
1658526-5
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694051
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
91
Package Type:
Tray
Type:
IDC Connector
Body Orientation:
Right Angle
Gender:
F
Mounting:
Cable Mount
Pitch:
2.54 mm
Number of Contacts:
10
Maximum Voltage Rating:
N/A
Maximum Current Rating:
1/Contact A
Termination Method:
IDT
Operating Temperature:
-55 to 125 °C

IN STOCK: 982

Can Ship immediately

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 455

Factory Lead-Time 7 Weeks

Price (USD)

Qty
Unit Price
5
$7.81
100
$5.81
250
$5.78
455
$5.75
910
$5.50
1,365
$5.39
1,820 +
$5.36
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
