2422C-SL005

Alpha Wire

Multi-Conductor Cable Tape High Density Polyethylene 2 Conductors 18AWG 5.38mm 300VAC - Slate - Reel - 30.48m (100ft)/Spool ...

Fiche technique

RoHS Compliant

Certificate of Compliance Guarantee

DESCRIPTION

The 2422C-SL005 is a two-conductor shielded cable assembly designed for low-voltage control and signal transmission applications. It features 18 AWG (16/30) tinned copper conductors with 0.016" FRPE insulation, an aluminum/mylar tape shield with 25% overlap and 20 AWG tinned copper drain wire, and a 0.020" PVC jacket in slate color. The cable is rated for 300V RMS at 75°C and meets UL AWM/STYLE 2092, CMG, and CSA C(UL) TYPE CMG FT4 standards. Key electrical characteristics include a characteristic impedance of 54O, capacitance of 31 pF/ft, and conductor DC resistance of 7O/1000ft at 20°C. The cable operates over a temperature range of -20°C to +75°C with a minimum bend radius of 10X cable diameter and maximum pull tension of 33 lbs. This shielded construction makes it ideal for applications requiring EMI protection in industrial control systems, instrumentation, and audio/video signal transmission.

Product Highlights:

Potential Applications:

Search Keywords: 2422CSL005

SPÉCIFICATION

Product Attribute

Attribute Value

Select Attribute

Products found: 0

fournisseur:

Alpha Wire

Référence:

2422C-SL005

Alias/AKA:

2422C-SLATE-100

Unité de mesure:

Per Each

RoHS:

Yes

HTS:

8544493080

COO:

ECCN:

EAR99

Référence: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
