6827-RD005
Hook Up Wire - Stranded - 16 (19/29) AWG - 300V - mPPE - Red - 100 ft - Tinned Copper ...
DESCRIPTION
The 6827-RD005 is a halogen-free hookup wire designed for general-purpose electrical applications. It features a 16 AWG bare copper conductor (19/29 stranding) with a 0.010" wall modified polyphenylene ether insulation, providing a nominal outer diameter of 0.076 inches. The wire is rated for 300V RMS at 110°C continuous operation and is suitable for ISO 6722 applications at 60V RMS. It operates reliably across a temperature range of -40°C to +110°C with a minimum bend radius of 10 times the cable diameter and a maximum pull tension of 19.1 lbs. This RoHS-compliant wire is ideal for automotive wiring, industrial control systems, and general-purpose interconnections where halogen-free construction and regulatory compliance are required.
Mots-clés de recherche: 6827RD005
SPÉCIFICATIONS
EN STOCK: 3
Peut être expédié immédiatement
Stock du fabricant: 45 Peut expédier 10/26/26
DÉLAI DE L'USINE 16 Semaines Peut expédier 2/1/27
Prix (CAD)
Outils/Modèles 3D
Shrink Tubing
Fiche technique
