Image is representational - see mfr. specs

86702CY-SL005

Multi-Pair Cable - 4 (2 Pair Twisted) Conductors - 22 AWG - 19/34 Conductor Strand - 300V - Slate Jacket - 30.48m (100ft)/Spool. ...

Fiche technique

RoHS Compliant

Reel Emballage

Certificate of Compliance Guarantee

DESCRIPTION

The 86702CY-SL005 from Alpha Wire is multi-pair cable with 4 (2 pair twisted) conductors, 22 AWG wire gauge, 19/34 conductor strand and 300V voltage rating. This cable has tinned copper conductor, poly-vinyl chloride (PVC) conductor insulation, aluminum/tinned copper foil/braid shield (100%/85% coverage) and slate color poly-vinyl chloride (PVC) jacket with 0.287" (7.29mm) diameter. Operating temperature range is from +5°C to 105°C.

Product Highlights:

Potential Applications:

Search Keywords: 86702CYSL005

SPÉCIFICATION

Product Attribute

Attribute Value

Select Attribute

Products found: 0

fournisseur:

Alpha Wire

Référence:

86702CY-SL005

Alias/AKA:

86702CY-SLATE-100

Unité de mesure:

Per Each

RoHS:

Yes

HTS:

8544493080

COO:

ECCN:

EAR99

Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
