AZ2160-1C-15DEF

American Zettler

40A Mini Power Relay 15VDC coil SPDT ...

Fiche technique

RoHS Compliant

Tray Emballage

Certificate of Compliance Guarantee

DESCRIPTION

AZ2160-1C-15DEF is a miniature power relay featuring a single Form C (SPDT) contact arrangement with 40 A switching capability and a 15 VDC nominal coil voltage. The relay offers both PC and quick-connect terminal options, with AgSnO2 (silver tin oxide) contact material and a contact resistance of =20 mO. It delivers a mechanical life expectancy of 10 million operations and an electrical life of 100,000 cycles at 125 VAC with 30 A Form A contacts. The relay operates over a temperature range of -55°C to 105°C (Class F coil), features a dielectric strength of 2500 VRMS (coil to load contacts), and meets UL 508 and UL 873 spacing requirements. This relay is ideal for industrial control applications, HVAC systems, and refrigeration equipment where reliable switching and compact form factor are essential.

Product Highlights:

Potential Applications:

Search Keywords: AZ21601C15DEF

SPÉCIFICATION

Product Attribute

Attribute Value

Select Attribute

Products found: 0

fournisseur:

American Zettler

Référence:

AZ2160-1C-15DEF

Unité de mesure:

Per Each

RoHS:

Yes

HTS:

8536410050

COO:

ECCN:

EAR99

Référence: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

350

Package Type:

Tray

EN STOCK: 1,628

Peut être expédié immédiatement

BONDED Quantity: 0

Manufacturer Stock: 0

Stock lot only:

Quantité minimale de commande pour qté en stock: 5

Quantité minimale de commande pour qté en rupture de stock: 263

Multiple: 1

DÉLAI DE L'USINE 14 Weeks

This product is no longer being manufactured but there may be alternatives. We can help you, NOUS JOINDRE.

PRICE (USD)

QTÉ

Prix unitaire

$11.58

$8.11

100

$7.56

263

$7.09

525

$7.03

788

$6.99

1 050 +

$6.94
