MS3102A24-10P
Conn MIL-DTL-5015 Circular PIN 7 POS Solder ST Box Mount 7 Terminal 1 Port ...
DESCRIPTION
The MS3102A24-10P is a MIL-DTL-5015 circular connector plug assembly featuring a 24-size shell with 10 contacts arranged in a specific insert configuration. This connector is designed for reliable electrical connections in military, aerospace, and industrial environments where durability and standardization are critical. The shell accommodates various contact sizes (0, 4, 8, 12, and 16) with crimp rear release termination, supporting wire ranges from 2–0 AWG (34–60 mm²) for size 0 contacts down to 20–16 AWG (0.5–1.4 mm²) for size 16 contacts. The connector features a threaded coupling mechanism with a 1.500–18 UNEF thread class 2A specification and is rated for contact retention of up to 30 lbf (133.4 N) axial load depending on contact size. Common applications include aircraft wiring harnesses, ground support equipment, and military vehicle electrical systems where proven reliability and interchangeability are essential.
Mots-clés de recherche: MS3102A2410P
SPÉCIFICATIONS
EN STOCK: 5
Peut être expédié immédiatement
sur commande:
91
Peut expédier 8/20/26
sur commande:
25
Peut expédier 11/30/26
DÉLAI DE L'USINE 16 Semaines
Prix (USD)
Outils/Modèles 3D
ressources
Fiche technique
