AT04-12PA-P026
The AT04-12PA-P026 is a 12-position, Keyed A, HYPERBUSS™ AT Series bussed receptacle connector designed for creating common electrical pathways in heavy-duty applications. ...
DESCRIPTION
The AT04-12PA-P026 is a 12-position bussed receptacle from the HYPERBUSS™ AT Series, used to create a common electrical junction for power distribution. This connector features a grey thermoplastic housing in a Keyed A configuration and is internally arranged as two separate 6-pin busses, with each buss rated for a maximum of 39A. It is equipped with size 16 nickel-plated copper alloy contacts and is designed to operate reliably in a temperature range of -55°C to +125°C. When mated with a corresponding AT06 series plug, it provides an IP67-rated seal for superior environmental protection. This robust connector is ideal for use as a splice or tap block in demanding industries such as transportation, marine, military, and agriculture.
Mots-clés de recherche: AT0412PAP026
SPÉCIFICATIONS
EN STOCK: 0
sur commande:
1 000
Peut expédier 12/4/26
Quantité minimale de commande: 5
DÉLAI DE L'USINE 16 Semaines
Prix (USD)
Product Drawing
Catalog/Flyer
3D CAD Drawing
Fiche technique
Learn more about Amphenol Sine Systems A Series™ Family of Connectors
