Image is representational - see mfr. specs

T3478000U

Amphenol Tuchel

Conn Circular F 7 POS Solder ST Panel Mount 7 Terminal 1 Port ...

Fiche technique

RoHS Compliant

EACH Emballage

Certificate of Compliance Guarantee

DESCRIPTION

T3478000U is an M16 D circular DIN connector from Amphenol's signalmate® C091 family, designed for industrial applications requiring robust environmental protection and EMI shielding. The connector features a metal screw coupling system, thermoplastic dielectric material, and silver/gold contact plating, with support for 2 through 8, 12, and 14 position configurations. It provides IP65/67/69K protection when mated and operates across a temperature range of -40°C to +100°C, with operating voltage up to 300V per IEC 60664-1 standard. The connector supports solder and crimp termination options with wire gauges from 18 to 28 AWG, and achieves excellent insulation resistance greater than 10¹² O and contact resistance less than 5 mO. This connector is ideal for measuring instruments, equipment, and 4G/5G mobile radio networks where reliable power and signal connections with superior EMI shielding are essential.

Product Highlights:

Potential Applications:

Search Keywords: T3478000U

SPÉCIFICATION

Product Attribute

Attribute Value

Select Attribute

Products found: 0

fournisseur:

Amphenol Tuchel

Référence:

T3478000U

Alias/AKA:

T-3478-000

Unité de mesure:

Per Each

RoHS:

Yes

HTS:

8536698000

COO:

ECCN:

EAR99

Référence: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
