VN0203600021C
A turned 3.6 mm socket crimp contact with silver plating for 16 mm² wire, designed for the heavy|mate® M series modular connectors. ...
DESCRIPTION
The VN0203600021C is a turned 3.6 mm socket crimp contact for use within the heavy|mate® M modular connector system. This silver-plated contact is constructed from CuZn (brass) and is specifically designed to terminate a 16 mm² (AWG 6) wire. It is intended for the 2-contact module, which features a rated voltage of 1000V, a rated current of 65A, and a contact resistance of ≤ 5 mΩ. The contact is engineered for robust performance, with a mechanical operation of at least 500 mating cycles. Its operational temperature range of -40°C to +125°C makes it suitable for demanding industrial power applications.
Mots-clés de recherche: VN0203600021C
SPÉCIFICATIONS
EN STOCK: 395
Peut être expédié immédiatement
Stock du fabricant: 1 500 Peut expédier 10/19/26
Quantité minimale de commande: 5
DÉLAI DE L'USINE 13 Semaines Peut expédier 1/11/27
Prix (CAD)
Product Drawing
Catalog/Flyer
Fiche technique
