SBS75GBLK-BK by anderson power products
Image non contractuelle - consultez les spécifications du fabricant
Anderson Power Products Distributeur agréé

SBS75GBLK-BK

SBS® 75G Standard Housing - Black ...

Voir la fiche technique Interroger la fiche technique
Conforme RoHS
Bulk Emballage
ACCESSOIRES
Certificat de conformité

DESCRIPTION

SBS®75G are available in wire-to-wire and wire-to-board configurations providing power contacts rated up to 110 amps. The SBS®75G features a third first-mate last-break ground or power contact. All contact positions are rated for circuit interruption (hot plugging).

Mots-clés de recherche: SBS75GBLKBK

SPÉCIFICATIONS

Attribut du produit
Valeur de l'attribut
Sélectionner un attribut
Produits trouvés : 0
fournisseur:
Anderson Power Products
Référence:
SBS75GBLK-BK
Alias/également connu sous:
SBS75GBLK
Unité de mesure:
Par Each
RoHS:
Yes
HTS:
8538907080
COO:
CN
ECCN:
EAR99
Conditionnement standard du fournisseur: Ces informations sont fournies aux clients qui préfèrent acheter par multiples de la quantité d
250
Type de boîtier:
Bulk
Montage:
Cable Mount
Orientation du corps:
Straight
Genre:
RCP
Méthode de terminaison:
Crimp
Nombre de contacts:
3
Tension maximale nominale:
80 V
Courant nominal maximal:
20 A
Température de fonctionnement:
-20 to 105 °C

EN STOCK: 630

Expédition today, Saisissez la valeur du paramètre.

sur commande: 5 000   Peut expédier 11/23/26

Quantité minimale de commande: 5

DÉLAI DE L'USINE 8 Semaines

Prix (CAD)

QTÉ
Prix unitaire
5
$9.907
50
$8.340
100
$7.863
250
$7.160
500
$7.020
1 000
$6.686
2 500
$6.668
5 000 +
$6.651
Emballage standard du fournisseur
Connectez-vous pour obtenir des prix spéciaux
