IZPP1F462
Switch Push Button ON OFF SPST Round Flat Button 0.1A 24VDC Latching Wire Lead Panel Mount Automotive ...
DESCRIPTION
IZPP1F462 is a rear-mounted sealed momentary pushbutton switch designed for panel mounting with a 16 mm bushing and flat actuator configuration. The switch features gold-plated contacts rated for 200 mA at 48 VDC with solder lug terminals, and is sealed to IP67 according to IEC 60529 for protection against dust and water ingress. It offers an electrical life of 500,000 cycles at full load with an initial contact resistance of 100 mO maximum and insulation resistance of 1 GO minimum at 500 VDC. The switch operates reliably across a temperature range of -40°C to +85°C and demonstrates excellent shock resistance (100 g per IEC 512-4, test 6c) and vibration resistance (10-500 Hz, 10 g per IEC 512-4, test 6d). This switch is ideal for industrial control panels, instrumentation, and applications requiring sealed, durable momentary switching with high reliability.
Mots-clés de recherche: IZPP1F462
SPÉCIFICATIONS
EN STOCK: 86
Peut être expédié immédiatement
Quantité minimale de commande pour qté en stock: 5
Quantité minimale de commande pour qté en rupture de stock: 5
DÉLAI DE L'USINE 10 Semaines
Fiche technique
Component Moment Extended Cut: APEM Pushbuttons
Learn more about APEM, Inc. High Performance I Series Pushbuttons
