LGA50D-01DADJSBJ
Non Isolated DC-DC Converter 2-Output 0.6V to 5V 50A 120W 28-Pin Surface Mount T/R ...
DESCRIPTION
The LGA50D-01DADJSBJ is a non-isolated dual-output digital DC/DC converter designed for cost and space-sensitive applications requiring high power density. It features two independent and configurable 25 A, 50 W outputs that can be combined into a single 50 A, 100 W output, with an adjustable output voltage range of 0.6–5.0 V and input voltage range of 7.5–14 Vdc. The converter achieves exceptional efficiency up to 95.5% at 5.0 V output, operates across a wide temperature range of -40°C to +85°C, and incorporates a two-phase design with automatic loop compensation and PMBus digital control. With a compact footprint of 1.0 × 0.5 × 0.48 inches (25.4 × 12.5 × 12.2 mm) and solder bump termination, it is reflow-compatible and can be stacked up to four units for 200 A total current. This converter is ideal for applications in telecommunications, data center computing, and industrial systems where space efficiency and thermal performance are critical.
Mots-clés de recherche: LGA50D01DADJSBJ
SPÉCIFICATIONS
EN STOCK: 190
Expédition today, Saisissez la valeur du paramètre.
Quantité minimale de commande pour qté en stock: 10
Quantité minimale de commande pour qté en rupture de stock: 50
DÉLAI DE L'USINE 12 Semaines
Fiche technique
