Image is representational - see mfr. specs

09-0174-90-08

M16 IP67 Female panel mount connector, Contacts: 8 (08-a), unshielded, THT, IP68, UL, AISG compliant, front fastened ...

Fiche technique

RoHS Compliant

Certificate of Compliance Guarantee

DESCRIPTION

09-0174-90-08 is an M16 female panel mount connector designed for industrial control and signal distribution applications. It features 8 contacts (08-a configuration) with a straight socket design, unshielded construction, and front mounting capability. The connector is rated IP68 for dust and water ingress protection, operates across a temperature range of -40°C to +95°C, and supports over 500 mating cycles with a screw locking system. Electrical specifications include a rated voltage of 60 V, rated current of 5.0 A, and insulation resistance of =10¹° O. The housing is zinc die-cast nickel-plated with PBT (UL94 V-0) contact body material and silver-plated bronze contacts, making it suitable for harsh environments in plant engineering, control equipment, and AISG-compliant applications.

Product Highlights:

Potential Applications:

Search Keywords: 0901749008

SPÉCIFICATION

Product Attribute

Attribute Value

Select Attribute

Products found: 0

fournisseur:

Binder-USA

Référence:

09-0174-90-08

Unité de mesure:

Per Each

RoHS:

Yes

HTS:

85369010

COO:

ECCN:

EAR99

Référence: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
