81A2A-G36-A15/A15L by bourns
Image is representational - see mfr. specs

81A2A-G36-A15/A15L

Bourns

A dual-section, single-turn cermet panel control potentiometer with two 10 kOhm linear taper sections and PC pin terminals. ...

Fiche technique
RoHS Compliant
Emballage
ACCESSOIRES
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 81A2A-G36-A15/A15L is a dual-section, single-turn panel control potentiometer designed for manual adjustments. It features a cermet resistive element for both sections, each providing 10 kOhms of resistance with a linear taper and a ±10% tolerance. This model is constructed with a 3/8-inch plain bushing, a dual concentric plain shaft (1/4" and 1/8" diameters) measuring 1-1/8" in length, and PC pin terminals for board mounting. As a RoHS compliant component with a rotational life of 100,000 cycles, it is well-suited for industrial controls, test equipment, and other applications requiring two independent adjustments from a single, durable control.

Search Keywords: 81A2AG36A15A15L

SPÉCIFICATION

Product Attribute
Attribute Value
Select Attribute
Products found: 0
fournisseur:
Bourns
Référence:
81A2A-G36-A15/A15L
Unité de mesure:
Per Each
RoHS:
Yes
HTS:
8533408070
COO:
HU
ECCN:
EAR99
Référence: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Mounting:
Panel Mount/Through Hole
Number of Turns:
1(Elec),1(Mech) Tur ns
Termination Style:
Pin
Power Rating:
1 W
Resistance Value:
10/10 KOhm
Tolerance:
10 %
Temperature Coefficient:
±150 ppm/°C
Dimension:
54.62 x 15.88 x 17.52 mm
Operating Temperature:
-40 to 125 °C
Switch Option:
No
Number of Elements:
2

EN STOCK: 37

Peut être expédié immédiatement

Quantité minimale de commande pour qté en rupture de stock: 68

DÉLAI DE L'USINE 9 Weeks

PRICE (USD)

QTÉ
Prix unitaire
1
$66.52
25
$42.95
68
$41.19
135
$40.78
203
$40.38
270 +
$39.97
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models
