RJR24FW102R by bourns
Image non contractuelle - consultez les spécifications du fabricant

RJR24FW102R

Bourns

Res Cermet Trimmer 1K Ohm 10% 0.5W(1/2W) 0.01% 25(Elec)Turns 2.19mm (9.53 X 4.83 X 11.55mm) Pin Thru-Hole Tube ...

Fiche technique
Non-Compliant
TUBE Emballage
ACCESSOIRES
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Garantie du certificat de conformité

DESCRIPTION

RJR24FW102R is a 3/8" square multiturn trimming potentiometer designed for industrial and sealed applications requiring high reliability and precision adjustment. This cermet-element device features a 1 kO nominal resistance with ±10% tolerance, infinite resolution, and 25 turns of effective travel, enabling precise voltage and resistance adjustability of ±0.01% and ±0.05% respectively. The potentiometer operates over a temperature range of -55°C to +150°C with a temperature coefficient of ±100 ppm/°C, maintains insulation resistance of 1,000 megohms at 500 VDC, and is rated for 0.5 watt at 85°C with a maximum dielectric strength of 1,000 VAC at sea level. It meets MIL-PRF-39035 high-reliability specifications with a 0.01% failure rate, includes 10,000-hour load life at 0.5 watt and 85°C, and is commonly used in instrumentation, signal conditioning, and precision calibration circuits where sealed, multiturn adjustment and military-grade performance are essential.

Search Keywords: RJR24FW102R

SPÉCIFICATION

Attribut du produit
Valeur de l'attribut
Sélectionner un attribut
Produits trouvés : 0
fournisseur:
Bourns
Référence:
RJR24FW102R
Unité de mesure:
Par Each
RoHS:
No
HTS:
8533408050
COO:
IE
ECCN:
EAR99
Référence: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
200
Package Type:
TUBE
Montage:
Through Hole
Nombre de spires:
25(Elec) Turns
Style de terminaison:
Pin
Puissance nominale:
0.5 (1/2) W
Valeur de résistance:
1 KOhm
Tolérance:
10 %
Coefficient de température:
±100 ppm/°C
Dimension:
9.53 x 4.83 x 11.55 mm
Température de fonctionnement:
-55 to 150 °C
Option d'interrupteur:
No
Nombre d'éléments:
1

EN STOCK: 156

Peut être expédié immédiatement

Commande min Quantitè: 5

DÉLAI DE L'USINE 10 Weeks

Prix (USD)

QTÉ
Prix unitaire
5
$10.73
25
$8.71
50
$8.00
200
$7.00
400
$6.98
600
$6.72
1 000
$6.59
2 600 +
$6.57
Emballage standard du fournisseur
