SRN5020-220M
Inductor Power Semi-Shielded Wirewound 22uH 20% 100KHz 11Q-Factor Ferrite 1A 312mOhm DCR 2020 T/R ...
DESCRIPTION
SRN5020-220M is a semi-shielded power inductor from Bourns designed for DC/DC converter applications and portable electronics. It features a 22 µH inductance with 20% tolerance, a maximum DC resistance of 0.312 O, and a rated RMS current of 1.0 A with a saturation current of 0.90 A. The inductor operates over a temperature range of -40°C to +125°C and has a self-resonant frequency of 13 MHz at 2.52 MHz test frequency. Its compact semi-shielded construction with a maximum component height of 2 mm, combined with ferrite core and enameled copper wire, makes it ideal for space-constrained applications such as notebook computers, digital video cameras, and LCD display systems.
Mots-clés de recherche: SRN5020220M
SPÉCIFICATIONS
EN STOCK: 6 000
Expédition today, Saisissez la valeur du paramètre.
Quantité minimale de commande: 2000
Ce modèle de message est utilisé pour informer un affilié qu'une certaine commande a été payée. La commande obtient le statut Payée lorsque le montant a été débité.: 2000
Fiche technique
MDS/SRN5020
Learn more about Bourns® Extensive Breadth of Magnetic Component Products
