SRN5020-4R7M by bourns
Image is representational - see mfr. specs

SRN5020-4R7M

Bourns

Inductor Power Semi-Shielded Wirewound 4.7uH 20% 100KHz 11Q-Factor Ferrite 2A 72mOhm DCR 2020 T/R ...

Fiche technique
RoHS Compliant
REEL Emballage
ACCESSOIRES
Discontinued & Replaced
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

SRN5020-4R7M is a semi-shielded power inductor from the Bourns SRN5020 series, designed for high-efficiency power conversion applications. It features an inductance of 4.7 µH with ±20% tolerance, a maximum DC resistance of 0.072 , and a self-resonant freR["Inductance: 4.7 µH","Inductance Tolerance: ±20%","DC Resistance (DCR): 0.072 max.","Rated RMS Current (Irms): 2.0 A","Saturation Current (Isat): 2.0 A","Self-Resonant Frequency (SRF): 30 MHz typ.","Q Factor: 11 (ref.) at 7.96 MHz","Operating Temperatu MAGNETICS

Search Keywords: SRN50204R7M

SPÉCIFICATION

Product Attribute
Attribute Value
Select Attribute
Products found: 0
fournisseur:
Bourns
Référence:
SRN5020-4R7M
Unité de mesure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
MY
ECCN:
EAR99
Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
2000
Package Type:
REEL
Inductance:
4.7 uH
Type:
Power
Impedance:
N/A
Tolerance:
20 %
Technology:
Wirewound
Maximum DC Current:
2 A
Maximum DC Resistance:
0.072 Ohm
Operating Temperature:
-40 to 125 °C
Packaging:
Tape and Reel
Protection Style:
Semi-Shielded
Life Cycle:
Discontinued & Replaced
  This product is discontinued, but still in stock

EN STOCK: 28,000

Expédition today, if you order in

Commande min Quantitè: 2000

Multiple: 2000

PRICE (USD)

QTÉ
Prix unitaire
2 000
$0.2678
4 000
$0.2619
6 000
$0.2606
8 000
$0.2537
10 000
$0.2407
26 000
$0.2364
50 000
$0.2353
100 000 +
$0.2340
Reel Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
Remplacement recommandé
SRN5020TA-4R7M
SRN5020TA-4R7M
VIEW PRODUCT
