TBU-CA065-200-WH by bourns
Image is representational - see mfr. specs

TBU-CA065-200-WH

Bourns

Transient Blocking Unit (TBU) - Bidirectional - 6.5 x 4 x 0.85 mm - Maximum impulse voltage 650V - Maximum RMS voltage 300V - 9.8 Ohm - Surface Mount. ...

Fiche technique
RoHS Compliant
REEL Emballage
ACCESSOIRES
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

High speed protector in surface mount DFN package. It is designed to protect against faults caused by short circuits, AC power cross, induction and lightning surges. Typical applications include voice / VDSL cards, protection modules and dongles, process control equipment, test and measurement equipment. Operating temperature ranges from -55°C to +125°C.

Search Keywords: TBUCA065200WH

SPÉCIFICATION

Product Attribute
Attribute Value
Select Attribute
Products found: 0
fournisseur:
Bourns
Référence:
TBU-CA065-200-WH
Unité de mesure:
Per Each
RoHS:
Yes
HTS:
8541590080
COO:
CN
ECCN:
EAR99
Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
3000
Package Type:
REEL
Maximum Blocking Time:
1 us
Maximum Impulse Voltage:
650 V
Maximum Operating Current:
N/A
Configuration:
Bi-Directional
Family:
TBU-CA
Dimension:
6.5mm x 4mm x 0.8mm

EN STOCK: 6,798

Peut être expédié immédiatement

Commande min Quantitè: 250

DÉLAI DE L'USINE 16 Weeks

PRICE (USD)

QTÉ
Prix unitaire
250
$0.897
500
$0.880
1 000
$0.863
3 000
$0.853
6 000
$0.801
9 000
$0.788
12 000
$0.786
15 000 +
$0.784
Reel Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

ressources

Product Changes
