AFB0412SHB-SP04 by delta thermal / emi / solenoids
Image non contractuelle - consultez les spécifications du fabricant

AFB0412SHB-SP04

Delta Thermal / EMI / Solenoids

DC Fans DC Axial Fan - 40x15mm - 12VDC - 14.83CFM - 1.92W - 0.16A - 41.5dBA - 11000RPM - Ball Bearing - PWM ...

Fiche technique
RoHS Compliant
Bulk Emballage
ACCESSOIRES
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Garantie du certificat de conformité

DESCRIPTION

Delta Electronics Ingress Protection Fans feature built-in resistance to environmental conditions such as dust, water and foreign objects that can disable and damage fans and thermal cooling equipment. Delta Electronics Ingress Protection (IP) fans provide IP55 and higher protection as an industry standard, offering protection against the intrusion of solid objects such as hands and fingers, as well as dust or dirt exposure, accidental contact, and water in the form of salt fog, moisture, or precipitation. Voltage - Rated 12VDC Size / Dimension Square - 40mm L x 40mm H Width 15.00mm Air Flow 14.8 CFM (0.414m³/min) Bearing Type Ball Fan Type Tubeaxial Features PWM Control, Speed Sensor (Tach) Noise 41.5 dB(A) Power (Watts) 1.92W RPM 11000 RPM Termination 4 Wire Leads Operating Temperature 14 ~ 158°F (-10 ~ 70°C) Weight 0.055 lb (24.95g) Current Rating (Amps) 0.160A Voltage Range 10.8 ~ 13.2VDC

Search Keywords: AFB0412SHBSP04

SPÉCIFICATION

Attribut du produit
Valeur de l'attribut
Sélectionner un attribut
Produits trouvés : 0
fournisseur:
Delta Thermal / EMI / Solenoids
Référence:
AFB0412SHB-SP04
Unité de mesure:
Par Each
RoHS:
Yes
HTS:
8414596590
COO:
CN
ECCN:
EAR99
Référence: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
448
Package Type:
Bulk
Catégorie:
DC Fan
Dimension:
40 x 40 x 15 mm
Tension nominale:
12 V
Puissance nominale:
1.92 W
Débit d'air maximal:
14.8 CFM
Niveau de bruit:
41.5 dB
Signal du tachymètre:
Yes
Signal de commande PWM:
Yes
Caractéristiques spéciales:
Tachometer Output, PWM speed control
Terminaison:
Lead Wires
Matériau du boîtier:
Plastic
Température de fonctionnement:
-10 to 70 °C

EN STOCK: 0

sur commande: 2 249   Peut expédier 11/23/26

Commande min Quantitè: 5

DÉLAI DE L'USINE 39 Weeks

Prix (USD)

QTÉ
Prix unitaire
5
$12.50
25
$10.61
50
$10.53
100
$10.48
448
$10.45
896
$10.42
1 344 +
$10.40
Emballage standard du fournisseur
Log in for special pricing Cliquez pour demander un devis Price Match Request

Outils/Modèles 3D

ressources
