100AWDP1T2B4M2QE by e-switch
Image non contractuelle - consultez les spécifications du fabricant

100AWDP1T2B4M2QE

E-Switch

Toggle Switch - DPDT - On-None-On - 120VAC/28VDC - 5A - Silver Plated Contacts - PC Mount - 1/4" Dia x .243" No Thread Bushing - No Hardware ...

Fiche technique
RoHS Compliant
Emballage
ACCESSOIRES
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Garantie du certificat de conformité

DESCRIPTION

The 100AWDP1T2B4M2QE is a DPDT toggle switch designed for general-purpose switching applications requiring reliable multi-position control. It features three selectable positions (ON-NONE-ON) with silver-plated contacts and is rated for 5 amps at 120VAC or 28 VDC, with a secondary rating of 2 amps at 250VAC. The switch exhibits excellent electrical characteristics including a maximum contact resistance of 10 milliohms, minimum insulation resistance of 1,000 megaohms, and dielectric strength of 1,000 V RMS at sea level. With a life expectancy of 30,000 make-and-break cycles at full load and compact PCB-mount dimensions, this switch is well-suited for industrial control panels, appliance interfaces, and general-purpose electrical switching applications where durability and consistent performance are essential.

Search Keywords: 100AWDP1T2B4M2QE

SPÉCIFICATION

Attribut du produit
Valeur de l'attribut
Sélectionner un attribut
Produits trouvés : 0
fournisseur:
E-Switch
Référence:
100AWDP1T2B4M2QE
Unité de mesure:
Par Each
RoHS:
Yes
HTS:
8536509065
COO:
CN
ECCN:
EAR99
Référence: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
540
Configuration pôles-directions:
2P2T (DPDT)
Configuration de l'interrupteur:
On None On
Pouvoir de coupure @ tension:
5@120VAC 28VDC A
Style d'actionneur:
Round Lever
Montage:
PC Mount
Taille du filetage:
N/R
Orientation du corps:
Straight
Type de borne:
PC Pins
Température de fonctionnement:
-30 to 85 °C

EN STOCK: 180

Peut être expédié immédiatement

Commande min Quantitè: 5

DÉLAI DE L'USINE 12 Weeks

Prix (USD)

QTÉ
Prix unitaire
5
$4.67
50
$3.48
100
$3.27
250
$2.99
540
$2.76
1 080
$2.69
2 700
$2.68
5 400 +
$2.67
Emballage standard du fournisseur
Log in for special pricing Cliquez pour demander un devis Price Match Request
