Image is representational - see mfr. specs

PV0H240SS

Anti-Vandal Pushbutton - 2A - 36VDC - OFF-(ON) - SPST - IP65 - Stainless Steel Housing/Actuator - Non-Illum - Solder Lug - 12mm Panel Mount. ...

Fiche technique

RoHS Compliant

Certificate of Compliance Guarantee

DESCRIPTION

The PV0H240SS is a stainless steel panel-mount pushbutton switch featuring a single-pole single-throw (SPST) momentary contact circuit with a high actuator design. It is rated for 2A at 36VDC with a maximum contact resistance of 50mO and silver contact material, providing reliable electrical performance. The switch offers IP67 ingress protection, operates over a temperature range of -40°C to 85°C, and is designed for panel mounting with an M12 x 0.75 thread and recommended panel cut-out of 1–6mm thickness. With 200,000 electrical life cycles and 1,500V RMS dielectric strength, this switch is well-suited for industrial control applications, machinery interfaces, and harsh environments requiring robust, sealed switching solutions.

Product Highlights:

Potential Applications:

Search Keywords: PV0H240SS

SPÉCIFICATION

Product Attribute

Attribute Value

Select Attribute

Products found: 0

fournisseur:

E-Switch

Référence:

PV0H240SS

Unité de mesure:

Per Each

RoHS:

Yes

HTS:

8536509065

COO:

ECCN:

EAR99

Référence: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
