4182NX by ebm-papst
Image is representational - see mfr. specs

4182NX

ebm-papst

DC Fan Axial Ball Bearing 12V 6V to 15V 105.9CFM 49dB 119 X 119 X 38mm ...

Fiche technique
RoHS Compliant
Box Emballage
ACCESSOIRES
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 4182NX is a 12VDC standard or basic speed Axial Fan with speed signal, ball bearing and terminal power connection. Die-cast aluminium housing and fibreglass-reinforced plastic (PA) impeller. Clockwise direction of rotation looking at rotor, inlet over bars direction of air flow, flat plugs 2.8 x 0.5mm connection with mounting bore hole of 3.7mm. The DC axial compact fan is suitable for high air performance with moderate pressure build-up. The flow of air through the fan blades is parallel to the rotation axis. 3200RPM Speed rating 4.9W Rated power -30 to 75°C Maximum ambient temperature range Protected against reverse polarity and locking Applications

Search Keywords: 4182NX

SPÉCIFICATION

Product Attribute
Attribute Value
Select Attribute
Products found: 0
fournisseur:
ebm-papst
Référence:
4182NX
Unité de mesure:
Per Each
RoHS:
Yes
HTS:
8414596090
COO:
HU
ECCN:
EAR99
Référence: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Box
Category:
DC Fan
Dimension:
119 x 119 x 38 mm
Voltage Rating:
12 V
Power Rating:
4.9 W
Maximum Airflow:
105 CFM
Noise Level:
49 dB
Special Features:
None
Termination:
Terminals
Housing Material:
DieCast Aluminum
Operating Temperature:
-30 to 75 °C

EN STOCK: 395

Peut être expédié immédiatement

DÉLAI DE L'USINE 13 Weeks

PRICE (USD)

QTÉ
Prix unitaire
1
$64.42
5
$61.93
10
$58.92
25
$58.14
50
$53.43
100
$52.11
250 +
$51.84
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
