5968000201 by fair-rite products
Image is representational - see mfr. specs

5968000201

Fair-Rite Products

Ferrite Core Toroid Core 68-Material 5.3nH ...

Fiche technique
RoHS Compliant
Bag Emballage
ACCESSOIRES
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 5968000201 is a 68-grade ferrite toroidal core manufactured by Fair-Rite Products, featuring a ring configuration that optimizes intrinsic ferrite material properties for electromagnetic applications. The core has an outer diameter (A) of 9.5 mm, inner diameter (B) of 4.75 mm, and height (C) of 3.3 mm, with an inductance factor (AL) of 5.3 nH minimum and an effective cross-sectional area (Ae) of 0.073 cm². It is supplied with burnished edges and can be optionally coated with Parylene C (for diameters =9.5 mm) or thermo-set plastic coating (for diameters =9.5 mm), with the plastic-coated variant withstanding a minimum breakdown voltage of 1000 Vrms. This toroid is widely used in power input filters, ground-fault interrupters, common-mode filters, and pulse and broadband transformers, offering reliable performance in demanding electromagnetic filtering and signal conditioning applications.

Search Keywords: 5968000201

SPÉCIFICATION

Product Attribute
Attribute Value
Select Attribute
Products found: 0
fournisseur:
Fair-Rite Products
Référence:
5968000201
Unité de mesure:
Per Each
RoHS:
Yes
HTS:
8548900100
COO:
US
ECCN:
EAR99
Référence: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
2400
Package Type:
Bag
Operating Temperature:
-55 to 125 °C
Inductance Tolerance:
N/A
Typical Inductance:
5.3(Min) nH
Dimension:
3.3 x 9.55594mm
Family:
5968000201
Core Material:
685587
Mounting:
N/A
Application:
Inductive Components5586
Type:
Toroid Core5597

EN STOCK: 6,500

Peut être expédié immédiatement

Commande min Quantitè: 100

DÉLAI DE L'USINE 9 Weeks

PRICE (USD)

QTÉ
Prix unitaire
100
$0.368
500
$0.221
2 400
$0.218
4 800
$0.204
7 200
$0.202
9 600 +
$0.200
Emballage standard du fournisseur
